 In order to meet the demands of the world’s leading automobile constructors, Ansible Motion’s product range consists of three series of DIL simulators.  Each series is uniquely defined by its level of driver immersion and architectural features, as described below.

products
delta-icon3 Theta series

Compact
Driver-in-the-Loop

uses

  • Real-time model verification and development
  • Driver interaction with sophisticated simulations

key features

  • Efficient form factor with realistic seating position and driver interfaces
  • High fidelity steering feedback; single display image generation; stationary reference base
Theta series data sheet
delta-icon2 Sigma series

Stationary
Driver-in-the-Loop

uses

  • Cross-functional product evaluation and virtual driving
  • Human factors; ergonomics; infotainment experiments

key features

  • Scalable form factor with realistic surroundings and select driver cues
  • High fidelity steering feedback; blended image projection; stationary reference base

Sigma series data sheet

Delta SeriesDelta series

Dynamic
Driver-in-the-Loop

uses

  • Expert driver evaluation of primary vehicle dynamics
  • Electronic system tuning; vehicle performance experiments

key features

  • Full form factor with realistic dynamic cockpit and multi-sensory immersion
  • High fidelity steering feedback; blended image projection; 6DOF motion cueing

Delta series data sheet


Ansible Motion’s Delta, Sigma, and Theta series simulators all share the following common characteristics:

common features

  • Computer systems built and tested to exacting performance standards
  • Direct software interfaces for compatibility with many external tools
  • Robust co-simulation toolset with high bandwidth communication
  • Multi-system low latency synchronization
  • Modular framework for future growth and adaptability
  • Availability of many standard and bespoke options
  • Cross-compatibility and model sharing between each series
  • On-going services and support for hardware and software



white paper:

Driving Simulator Technology and How Automotive Manufacturers Will Benefit

Download

product selection guide


Driver-in-the-Loop simulation use cases

delta-icon3
Theta series
delta-icon2
Sigma series
delta-icon1
Delta series
Assist with development projects for road car, motorsports, and special vehicles
Implement a new damper physics model from a supplier; test its real-time function and its influence on steering vibration level
Test a newly developed tire model for its influence on vehicle turn-in feeling on five different road surfaces
Evaluate three new proving ground handling course designs in advance of construction
Refine a prototype vehicle handling test plan by pre-driving several of the tuning setups that were suggested by an off-line simulation DOE
Survey fifty non-expert drivers for specific behaviours in response to discrete Electronic Stability Control (ESC) settings

Simultaneous multi-continent manager virtual ride & drive to evaluate a defined range of ECU settings that interact with a Collision Mitigation Braking (CMB) system

Isolate key traction control and stability control interplay settings in order to streamline an upcoming test programme

Create safe experiments for monitoring common driver reactions to specific autonomous control hand-overs

Subjective evaluation of second round tire submissions from two suppliers, with focus on yaw-from-steer response and turn-in linearity



Accumulate virtual testing hours on a new race rack; professional driver gains lap experience while race engineers pre-qualify the driver’s wing setting preferences


Prepare for an upcoming evaluation event by pre-testing high speed stability with three expert drivers and ten distinct rear suspension geometry changes


Safely evaluate a matrix of extreme suspension, tire, and vehicle loading conditions for Fishhook and J-turn manoeuvres



request a DIL simulator project assessment

 Sign Up

hardware and software compatibility guide

rFpro
Sim Pack
Dymola
Matlab Simulink
IPG
dSPACE
Vires
Concurrent
CarSim
AVL
@source podium technology
Modelica
Cosworth
Telasys DYNAware
trucksim mechanical simulation
Bruel and Kjaer
Harman
MapleSim
VI-CarRealTime


we connect seamlessly with these and many other leading solutions
